    VDHT 3/4 EAM NC, Industrial

    Kód: 180L0297
    Neohodnoceno
    19 630,78 Kč
    Momentálně nedostupné

    Detailní popis produktu

    Popis produktu není dostupný

    Doplňkové parametry

    Kategorie: VDHT 3/2
    Hmotnost: 1.54 kg
    EAN: 5715162673584
    Media temperature [°C] [Min]: 2
    Flow [gpm] [Min]: 0.300
    Closing Time [ms] [Max]: 250
    Closing Time [ms] [Min]: 250
    Type of accessory/spare part: Other
    Outlet connection size [in]: 3/8 in
    Actuator size [mm]: 13.5
    Product description: Solenoid operated valves
    Connection standard: BSP
    China RoHS compliance: Out of scope
    In scope of WEEE: No
    Media temperature [°F] [Max]: 122
    Media temperature [°F] [Min]: 37
    Height: 128
    Drain connection size [in]: 0.250
    Type designation: VDHT 15 E NC-NC
    REACH Candidate List substances: No
    Piston diameter Ø [mm]: 18
    Inlet connection size [in]: 3/8 in
    Number of ways: 3/2
    Opening time [ms] [Max]: 250
    Function: NC; NC
    Contain batteries: No
    Opening time [ms] [Min]: 250
    Width: 128
    Operating pressure [barg] [Max]: 140
    Flow [l/min] [Max]: 15.00
    EU RoHS exemption clause: No
    Operating pressure [barg] [Min]: 2
    EU RoHS compliance: Yes
    Flow [l/min] [Min]: 1.00
    Operating pressure [psig] [Max]: 2000
    Media temperature [°C] [Max]: 50
    Flow [gpm] [Max]: 4.000
    Operating pressure [psig] [Min]: 29
    Spare part: TRUE
    Serviceable: Ano
    Seal Material: FKM
    Operation: Direct pilot operated
    Material type: Neutrální média
    Accessory: TRUE
    Connection type: Závit
    Direction: Přímý
    Parts Program name: VDHT
    Body material: AISI 304
    Application: Industrial
