Solenoid operated valves, VDHT 1/2 EA NC, Industrial

Kód: 180L0188

Neohodnoceno

13 065,78 Kč

Momentálně nedostupné

Popis produktu není dostupný

Kategorie:	VDHT BSP
Hmotnost:	1.18 kg
EAN:	5715162672037
Media temperature [°C] [Min]:	2
Flow [gpm] [Min]:	0.000
Closing Time [ms] [Max]:	300
Closing Time [ms] [Min]:	200
Type of accessory/spare part:	Other
Outlet connection size [in]:	1/2 in
Actuator size [mm]:	13.5
Product description:	Solenoid operated valves
Connection standard:	BSP
China RoHS compliance:	Out of scope
UL evaluated:	Yes
In scope of WEEE:	No
Media temperature [°F] [Max]:	194
Approval:	UL
Media temperature [°F] [Min]:	36
Height:	127
Type designation:	VDHT 1/2 EA NC
SCIP dossier no.:	3239369c-314a-4770-a216-7ff7ac4c6353
REACH Candidate List substances:	Lead (CAS no. 7439-92-1)
Piston diameter Ø [mm]:	18
Inlet connection size [in]:	1/2 in
Number of ways:	2/2
Opening time [ms] [Max]:	140
Function:	NC
Contain batteries:	No
Opening time [ms] [Min]:	120
Width:	127
Operating pressure [barg] [Max]:	160
Flow [l/min] [Max]:	60.00
EU RoHS exemption clause:	No
Operating pressure [barg] [Min]:	4
EU RoHS compliance:	Yes
Flow [l/min] [Min]:	0.00
Operating pressure [psig] [Max]:	2400
Media temperature [°C] [Max]:	90
Flow [gpm] [Max]:	16.000
Operating pressure [psig] [Min]:	51
Spare part:	TRUE
Serviceable:	Ano
Seal Material:	FKM
Operation:	Ovládaný pilotním ventilem
Material type:	Neutrální média
Accessory:	TRUE
Connection type:	Závit
Direction:	Rohový
SCIP dossier product name:	VDHT NC BSP Valves
Parts Program name:	VDHT
Body material:	AISI 304
Application:	Industrial
