Solenoid operated valves, VDHT 15 E NC-NO, Industrial

Kód: 180L0174

Neohodnoceno

19 904,30 Kč

Momentálně nedostupné

Průtok [gpm] [Max]: 4, Průtok [l/min] [Max]: 15, Provozní tlak [barg] [Max]: 140, Provozní tlak [psig] [Max]: 2000, Standard připojení: NPT

Průtok [gpm] [Max]: 4, Průtok [l/min] [Max]: 15, Provozní tlak [barg] [Max]: 140, Provozní tlak [psig] [Max]: 2000, Standard připojení: NPT

Kategorie:	VDHT 3/2
Hmotnost:	1.53 kg
EAN:	5715162672600
Media temperature [°C] [Min]:	2
Flow [gpm] [Min]:	0.300
Closing Time [ms] [Max]:	250
Closing Time [ms] [Min]:	250
Type of accessory/spare part:	Other
Outlet connection size [in]:	3/8 in
Actuator size [mm]:	13.5
Product description:	Solenoid operated valves
Connection standard:	NPT
China RoHS compliance:	Out of scope
In scope of WEEE:	No
Media temperature [°F] [Max]:	122
Media temperature [°F] [Min]:	37
Height:	127
Drain connection size [in]:	0.250
Type designation:	VDHT 15 E NC-NO
REACH Candidate List substances:	No
Piston diameter Ø [mm]:	18
Inlet connection size [in]:	3/8 in
Number of ways:	3/2
Opening time [ms] [Max]:	250
Function:	NC
Contain batteries:	No
Opening time [ms] [Min]:	250
Width:	127
Operating pressure [barg] [Max]:	140
Flow [l/min] [Max]:	15.00
EU RoHS exemption clause:	No
Operating pressure [barg] [Min]:	2
EU RoHS compliance:	Yes
Flow [l/min] [Min]:	1.00
Operating pressure [psig] [Max]:	2000
Media temperature [°C] [Max]:	50
Flow [gpm] [Max]:	4.000
Operating pressure [psig] [Min]:	29
Spare part:	TRUE
Serviceable:	Ano
Seal Material:	FKM
Operation:	Direct pilot operated
Material type:	Neutrální média
Accessory:	TRUE
Connection type:	Závit
Direction:	Přímý
Parts Program name:	VDHT
Body material:	AISI 304
Application:	Industrial
