PAH pumps, PAH 4
Kód: 180B0022Detailní popis produktu
Popis produktu není dostupný
Doplňkové parametry
| Kategorie: | Pumpy pro vodu |
|---|---|
| Hmotnost: | 4.72 kg |
| EAN: | 5715162666906 |
| Media temperature [°C] [Min]: | 2 |
| Flow [gpm] [Min]: | 0.500 |
| Outlet connection standard: | BSPP |
| Inlet connection standard: | BSPP |
| Outlet connection size [in]: | 1/4 in |
| Product description: | PAH pumps |
| Outside dimensions of packaging LxWxH [in]: | 10,7x5,9x5,4 |
| Outlet pressure [barg] [Max]: | 140 |
| Outside dimensions of packaging LxWxH [mm]: | 274x151x137 |
| Outlet connection type: | Závit |
| Inlet pressure [psig] [Max]: | 58.0 |
| Outlet pressure [barg] [Min]: | 10 |
| China RoHS compliance: | Out of scope |
| Inlet pressure [psig] [Min]: | 0.0 |
| Ambient temperature [°C] [min]: | 0 |
| UL evaluated: | Out of scope |
| In scope of WEEE: | No |
| Media temperature [°F] [Max]: | 122 |
| Approval: | CE |
| Media temperature [°F] [Min]: | 36 |
| Displacement [in³/rev]: | 0.24 |
| Type designation: | PAH 4 |
| Speed [rpm] [Max]: | 1800 |
| Speed continuous [rpm] [Min]: | 700 |
| REACH Candidate List substances: | No |
| Speed [rpm] [Min]: | 700 |
| Inlet connection size [in]: | 1/2 in |
| Sound pressure level [dB(A)]: | 76 |
| Contain batteries: | No |
| Outlet pressure [psig] [Max]: | 2030 |
| CE evaluated: | Yes |
| Ambient temperature [°F] [min]: | 32 |
| Flow [l/min] [Max]: | 6.40 |
| Outlet pressure [psig] [Min]: | 145 |
| EU RoHS compliance: | Out of scope |
| Flow [l/min] [Min]: | 1.90 |
| Media temperature [°C] [Max]: | 50 |
| Flow [gpm] [Max]: | 1.600 |
| Serviceable: | Ano |
| Seal Material: | NBR |
| Drain connection standard: | Metrický |
| Country of origin: | Dánsko |
| Inlet pressure [barg] [Max]: | 4.0 |
| Inlet pressure [barg] [Min]: | 0.0 |
| Ambient temperature [°C] [max]: | 50 |
| ATEX compliance: | No |
| Displacement [cm³/rev]: | 4.00 |
| Drain connection size (metric): | M6 |
| Body material: | AISI 304 |
| Drain connection type: | Závit |
| Inlet connection type: | Závit |
| Ambient temperature [°F] [max]: | 122 |
-
PAH/PAHT 2-12.5 Instruction: Instalační příručka
-
PAH 2-12.5 Installation, Opearation and Maintenance manual: Provozní příručka
-
PAH 2-6.3, PAHT 2-6.3, PAHT C 2-6.3 and PAHT G 2-6.3 Disassembling and assembling: Servisní příručka
-
Data sheet PAH pumps: Datový list
-
Moscow office complex saves 180 m2 with compact fire suppression system powered by Danfoss PAH pumps: Popis řešení
